| Nominal sensing distance | 0,3 … 2m |
| Thermal drift of Sr | ≤10% |
| Beams space | 10mm |
| controlled height | 90mm |
| minimum detectable object | Ø 5mm |
| number of rays | 10 |
| Function Principle | Receiver |
| Output type | NPN + PNP |
| Output Function | NO |
| Switching frequency | 180Hz |
| Resposnse time for light/dark transition | 500µs |
| Resposnse time for dark/light transition | 5ms |
| Operating Voltage | 10…26VDC |
| No-Load supply current | 50mA |
| Load current | ≤100mA |
| Leakage current | 10μA |
| Output voltage drop | ≤2V Iload = 100mA |
| Max ripple content | ≤ 10% |
| LED indicators | Yellow (output state) Red (alineament) |
| Time delay before availability | ≤ 85ms |
| Short-circuit protection | autoreset |
| Reverse Polarity Protection | Yes |
| Interference to external light | 1000lux (incandescent lamp), 1500lux (sunlight) |
| Impulsive Overvoltage Protection | Yes |
| Dimensions | 45mm x 145mm x 20mm |
| Weight | 300g |
| Housing Material | PBT |
| Connections | PVC 2m cable |
| Active Head Material | PC |
| Tightening torque | 25Nm |
| Operating temperature | 0°C…+ 50° C (without freeze) |
| Approvals | CE cULus |
| EMC compatibility | EN 60947-5-2 |
| Degree of protection | IP67 |
| Supplied Accessories | 2 nuts M18x1 - 1 adjustment key - 1 90°angled brackets |
| Dimensions | 45x145x20 |
| Operating Temperature | 0°C…+ 50° C (without freeze) |
| Mechanical Protection | IP67 |
